HPE7-A02 Questions Bank

When using OpenSSL to obtain a certificate signed by a Certification Authority (CA), you should submit the Certificate Signing Request (CSR) file, which is file1.pem, to the CA. The CSR contains the information about the entity requesting the certificate and the public key, but not the private key, which is in file2.pem. The CA uses the information in the CSR to create and sign the certificate.

1.CSR Submission: The CSR (file1.pem) includes the public key and the entity information required by the CA to issue a certificate.

2.Private Key Security: The private key (file2.pem) should never be sent to the CA or shared; it remains securely stored on the requestor’s server.

3.Certificate Issuance: After the CA signs the CSR, the resulting certificate can be used with the private key to establish secure communications.

Why a Mirror Session Is the Correct Choice

To analyze a wired client’s traffic with Wireshark, you need the traffic mirrored to your management station where Wireshark is installed. The most effective way to achieve this is by configuring a mirror session on the AOS-CX switch, specifying the client port as the source and your management station as the destination.

Analysis of Each Option

A. Access the client's switch's CLI from your management station. Access the switch shell and run a TCP dump on the client port:

Incorrect:

AOS-CX switches do not natively support packet capture (e.g., tcpdump) directly on the switch CLI.

This approach is not feasible for capturing and analyzing live client traffic.

B. Go to the client's switch in HPE Aruba Networking Central. Use the "Security" page to run a packet capture:

Incorrect:

HPE Aruba Networking Central provides security insights but does not directly support initiating packet captures for detailed analysis.

Traffic analysis with tools like Wireshark requires local packet capture at the management station.

C. Set up a policy that implements a captive portal redirect to your management station. Apply that policy to the client's port:

Incorrect:

Captive portals are designed for user authentication and redirection, not traffic analysis.

This would disrupt the client’s network activity without enabling traffic analysis in Wireshark.

D. Set up a mirror session on the client's switch; set the client port as the source and your station IP address as the tunnel destination:

Correct:

Mirroring the client port to your management station is the standard method for analyzing live network traffic with Wireshark.

Steps include:

Configure a mirror session on the client’s AOS-CX switch.

Set the client’s port as the source.

Set your management station as the destination using its IP address (via GRE tunnel or physical interface).

Start capturing traffic with Wireshark on the management station.

Final Recommendation

To analyze the client's traffic, configure a mirror session on the switch, set the client port as the source, and direct the traffic to your management station where Wireshark is running.

References

AOS-CX Switch Port Mirroring Configuration Guide.

HPE Aruba Networking Central Monitoring and Troubleshooting Best Practices.

Wireshark Traffic Analysis and Capture Techniques.

In the exhibit, the HPE Aruba Networking Central settings for the 9x00 gateway show that traffic inspection is enabled, and the gateway is set to operate in IDS (Intrusion Detection System) mode with the fail strategy set to "Block". This configuration means that the gateway will drop traffic if it matches a rule in the active ruleset.

1.Active Ruleset: The ruleset version 9861 is active, and the gateway is configured to automatically update the ruleset daily.

2.Traffic Matching Rules: When traffic matches a rule in the active ruleset, it is flagged as suspicious or malicious.

3.Block Mode: Since the fail strategy is set to "Block", any traffic that matches a rule in the active ruleset will be dropped to prevent potential threats.

Contextual Exchange for Better Decisions:

HPE Aruba ClearPass can integrate with third-party solutions like MDM and firewalls to exchange contextual information about endpoints (e.g., device type, posture, location).

This integration allows ClearPass and the third-party solutions to make better access control and security decisions.

For example:

An MDM can inform CPPM about device compliance, and CPPM can adjust enforcement policies dynamically.

Firewalls can receive updated context about users and devices to enforce policies more effectively.

Option Analysis:

Option A: Correct. Exchanging contextual information improves access control decisions.

Option B: Incorrect. CPPM does not provide signature-based threat detection.

Option C: Incorrect. CPPM does not offload policy decisions; it integrates for collaboration.

Option D: Incorrect. CPPM does not replace third-party traffic filtering capabilities.
