Cisco Certified Network Associate Questions and Answers

Question 13

Configure IPv4 and IPv6 connectivity between two routers. For IPv4, use a /28 network from the 192.168.1.0/24 private range. For IPv6, use the first /64 subnet from the 2001:0db8:aaaa::/48 subnet.

1. Using Ethernet0/1 on routers R1 and R2, configure the next usable/28 from the 192.168.1.0/24 range. The network 192.168.1.0/28 is unavailable.

2. For the IPv4 /28 subnet, router R1 must be configured with the first usable host address.

3. For the IPv4 /28 subnet, router R2 must be configured with the last usable host address.

4. For the IPv6 /64 subnet, configure the routers with the IP addressing provided from the topology.

5. A ping must work between the routers on the IPv4 and IPv6 address ranges.

Options:

Question 14

What does the term "spirt MAC” refer to in a wireless architecture?

Options:

A.

divides data link layer functions between the AP and WLC

B.

combines the management and control functions from the data-forwarding functions

C.

uses different MAC addresses for 2.4 GHz and 5 GHz bands on the same AP

D.

leverages two APs to handle control and data traffic

Question 15

Refer to the exhibit. How will the device handle a packet destined to IP address 100.100.100.100?

Options:

A.

If will choose the route with the longest match.

O 100.100.100.100'32 (110/21) via 192.168.1.1. 00:05:57. EmernetO/1.

B.

It will always prefer the static route over dynamic routes and choose the route

S 100.100.0.0/16(1/0] via 192.168.4.1.

C.

It will choose the route with the highest metric.

D 100.100.100.0/24 (90/435200) via 192.168.2.1. 00:00:13. EthernetO/2.

D.

It will choose the route with the lowest metric,

R 100.0.0.0/8 [120/2] via 192.168.3.1. 00:00:13. EthernetO/3.

Question 16

What is the difference between controller-based networks and traditional networks as they relate to control-plane and/or data-plane functions?

Options:

A.

Controller-based networks centralize all important data-plane functions, and traditional networks distribute data-plane functions.

B.

Controller-based networks centralize all important control-plane functions, and traditional networks distribute control-plane functions.

C.

Traditional networks centralize all important control-plane functions, and controller-based networks distribute control-plane functions.

D.

Traditional networks centralize all important data-plane functions, and controller-based networks distribute data-plane functions.
