200-301 Exam Dumps : Cisco Certified Network Associate

IPsec encryption mode is the way IPsec secures the data packets that are sent over an IP network. There are two main modes of IPsec encryption: tunnel mode and transport mode1. Tunnel mode encrypts the entire IP packet, including the original header, and adds a new IP header with the source and destination addresses of the security gateways (routers, firewalls, or VPN servers) that perform the encryption and decryption2. Transport mode encrypts only the payload (data) of the IP packet, leaving the original header intact, and uses the original source and destination addresses of the endpoints that generate and consume the data3. Therefore, transport mode is appropriate when the destination of a packet differs from the security termination point, as it does not change the original IP header information. Tunnel mode is more suitable when the security termination point is also the destination of the packet, as it provides more protection for the original IP header information.

The trunk still forms with mismatched native VLANs and the traffic can actually flow between mismatched switches. But it is absolutely necessary that the native VLANs on both ends of a trunk link match; otherwise a native VLAN mismatch occurs, causing the two VLANs to effectively merge.

For example with the above configuration, SW1 would send untagged frames for VLAN 999. SW2 receives them but would think they are for VLAN 99 so we can say these two VLANs are merged.
