The configuration set that accomplishes the goals of allowing communication between the external subnet and internal EPG1, as well as leaking L30ut traffic into VRF named “VF1”, is option D: Export Route Control Subnet Import Route Control Subnet Aggregate Shared Routes. This configuration ensures that routes are properly exported from one entity and imported into another while aggregating shared routes for efficient routing within the VRF “VF1”. It allows for controlled route leaking which is necessary for communication across different entities within a Cisco ACI environment. References := ( Implementing Cisco Application Centric Infrastructure Official Cert Guide )

An application-centric design in Cisco ACI focuses on the application requirements and interactions between different application components. In this design, EPGs (Endpoint Groups) represent different application tiers, such as web, application, and database tiers. This approach allows for a more flexible and scalable network configuration that aligns with the application architecture, enabling policies to be applied based on the application’s needs rather than the network topology. References := Implementing Cisco Application Centric Infrastructure Official Cert Guide

When a host connected to a Cisco ACI fabric leaf switch sends an ARP request, the ingress leaf switch uses a broadcast transmission method to send the ARP requests. This is because ARP requests are meant to discover the MAC address associated with a specific IP address within the same network broadcast domain. The ingress leaf switch does not know the destination MAC address, so it broadcasts the ARP request to all devices within the broadcast domain1.

References := ( Implementing Cisco Application Centric Infrastructure Official Cert Guide )

To ensure the Cisco ACI fabric adheres to strict security protocols and only learns endpoints from configured subnets on a bridge domain, the “Enforce Subnet Check” feature must be enabled. This feature restricts endpoint learning to IP addresses belonging to the subnets defined in the bridge domain associated with the endpoint’s VLAN, enhancing security by preventing learning of endpoints from unconfigured subnets. References: Implementing Cisco Application Centric Infrastructure Official Cert Guide

To allow reachability to services outside of the Cisco ACI fabric while conserving TCAM resources, an engineer should use a contract insertion method where L30ut external EPGsact as providers and vzAny inside VRF acts as consumers. This configuration allows for communication from all EPGs within a VRF (represented by vzAny) to access external services through L30ut without having to create individual contracts for each service EPG, thus saving TCAM resources. References: Implementing Cisco Application Centric Infrastructure Official Cert Guide

 In a Cisco ACI Multi-Site setup, the ISN (Inter-Site Network) connects different ACI sites. For efficient multicast traffic routing, BIDIR-PIM (Bidirectional Protocol Independent Multicast) is configured throughout the ISN, which is why option B is correct. Increasing the ISN MTU (Maximum Transmission Unit) to support the maximum MTU sent by endpoints is crucial to prevent packet fragmentation or loss, making option C correct.

Options A, D, and E are not typically required for an ACI Multi-Site setup. Direct connectivity between Spine switches and ISN routers, as mentioned in options A and D, is usually established through leaf switches. Option E, enabling IGMPv3 on ISN routers, is more relevant for managing multicast subscriptions within a single site.

References: = Implementing Cisco Application Centric Infrastructure Official Cert Guide

The best practices for configuring NIC teaming load balancing for Cisco UCS B-Series blades connected to Cisco ACI leaf switches involve enabling LACP (Link Aggregation Control Protocol) in active mode and enabling MAC pinning.

LACP active mode (option B) allows for the automatic bundling of several physical links into a single logical link, providing redundancy and increased bandwidth. This mode actively tests the link to ensure its functionality, which is essential for maintaining a stable connection.

MAC pinning (option E) is a method that assigns a virtual machine’s MAC address to a specific uplink. This ensures consistent forwarding paths for traffic within the same session, which is crucial for avoiding potential traffic distribution issues that could arise from dynamic changes in the network topology.

Creating vPC+ (option A) and vPC (option D) are not recommended as they are related to virtual port channels, which are not applicable in this scenario.PAgP (Port Aggregation Protocol) (option C) is Cisco’s proprietary protocol similar to LACP, but it is not the recommended practice in this context.

References :=

Implementing Cisco Application Centric Infrastructure Official Cert Guide

Cisco’s documentation on UCS B-Series Teaming Bonding Options

PBR Node Tracking:

Purpose: It is used to monitor the health and availability of endpoints within an Endpoint Group (EPG).

Functionality: When configured, it allows for real-time health checks and traffic redirection based on endpoint status and network conditions.

Benefits: Ensures traffic is directed to healthy endpoints, maintaining application performance and availability.

 To establish intra-VRF communication between two EPGs deployed across different sites with different bridge domains, stretching the bridge domain and EPG components is necessary. Option D, “bridge domain,” and Option E, “EPG,” must be configured as stretched to facilitate communication across different sites within the same VRF. References:= Implementing Cisco Application Centric Infrastructure Official Cert Guide

 In Cisco ACI fabric, STP BPDUs are flooded in the bridge domain VLAN. This allows the BPDUs to be propagated throughout the fabric, maintaining the STP topology2.

References := Implementing Cisco Application Centric Infrastructure Official Cert Guide

 For the ISN implementation between Cisco ACI data centers using Multi-Site, OSPF must be configured on subinterfaces for dynamic routing, and BIDIR-PIM must be set up on all ISN routers for efficient bidirectional multicast traffic routing. References := (Implementing Cisco Application Centric Infrastructure Official Cert Guide)

In a network-centric design within Cisco ACI, there is open communication between EPGs, and a bridge domain typically has one subnet and one EPG. This design is often used for initial migrations and is based on traditional networking concepts.

References := Network Centric to ACI Centric Migration - Cisco

To address resource overconsumption on a border leaf switch, migrating L3Outs to another switch can help distribute the load and reduce strain on the affected switch.

References := Implementing Cisco Application Centric Infrastructure Official Cert Guide

 To limit both local and remote endpoint learning to instances where the source IP address belongs to a bridge-domain subnet in the VRF instance, the action that should be taken inside the Cisco APIC is to enable the “Enforce Subnet Check” feature. This configuration ensures that IP addresses outside the configured subnets for the bridge domain are not learned, preventing mis-learning of IP addresses that do not belong to the fabric12.

 In Cisco ACI, shared services like firewalls should be configured in the common tenant. This allows all tenants to access the services without duplicating them in each tenant.

The L2 Stretch feature allows for the extension of a Layer 2 network across multiple sites without changing the IP addressing scheme, which satisfies the requirement for starting an application at a DR site without re-IPing servers. Disabling inter-site BUM (Broadcast, Unknown unicast, and Multicast) traffic prevents broadcast storms between sites while still allowing IP mobility, meeting both specified criteria. References := (Implementing Cisco Application Centric Infrastructure Official Cert Guide)

 For a full mesh Cisco ACI Multi-Site architecture, configuring the BGP-EVPN Router-ID on each spine is essential. This configuration ensures unique identification and proper routing of traffic within the overlay network1

Enabling ARP flooding is necessary when VMs are migrated from a pre-existing network to Cisco ACI and their gateways remain in the legacy setup. This allows the ACI fabric to learn about silent hosts that do not initiate communication, ensuring that the migrated VMs can communicate with all hosts in the network, including those that are silent.

In a Cisco ACI Multi-Pod deployment, the spine switches within a pod should not be directly connected to the spine switches in another pod. Instead, they should be connected to an IPN (Inter-Pod Network) device that provides Layer 3 IP connectivity between the pods. This setup allows for the extension of the ACI fabric across multiple locations while maintaining a single logical fabric. The IPN device can be a router or a switch with Layer 3 capabilities that can handle the necessary routing protocols and encapsulation methods required for Multi-Pod communication. References := Implementing Cisco Application Centric Infrastructure Official Cert Guide

Graphical user interface Description automatically generated

 In a Cisco ACI Multi-Pod environment that is expanding, spine headend replication should be configured to ensure efficient forwarding of BUM (Broadcast, Unknown unicast, Multicast) traffic across the IPN (Inter-Pod Network). This configuration optimizes the control plane scaling and ensures that BUM traffic is handled effectively, maintaining network performance and stability.

References: Implementing Cisco Application Centric Infrastructure Official Cert Guide

For shared L3Out network connectivity among different tenants in a Cisco ACI fabric, a common tenant is necessary. It provides a global space for defining resources like L3Outs once, which can then be utilized by multiple tenants, simplifying management and ensuring consistent policy application. References := ( Implementing Cisco Application Centric Infrastructure Official Cert Guide )

Table Description automatically generated

 To enable communication between the subnets 192.168.1.0/24 and 172.18.1.0/24 using Cisco ACI fabric, it is necessary to configure the subnets appropriately. For option B, setting 172.18.1.0/24 as an External subnet for an external EPG under L3out_A allows it to be recognized as part of an external network, facilitating communication with other networks within the ACI environment. Similarly, for option D, configuring 172.18.1.0/24 with the Export Route Control scope under L3out_B ensures that this route is advertised out of L3out_B, allowing it to reach other network segments, including those connected via L3out_A where the subnet 192.168.1.0/24 resides. These configurations are crucial for proper routing between these two distinct subnets across the Cisco ACI fabric.

References := ( Implementing Cisco Application Centric Infrastructure Official Cert Guide )

When traffic to certain endpoints is dropped in a Cisco ACI fabric configured with hardware proxy, setting the L2 Unknown Unicast option to Flood for Layer 2 switched traffic can prevent this problem. This mode allows unknown unicast traffic to be flooded within the bridge domain, rather than being sent to the spine proxy and potentially discarded if the destination is unknown5.

References := Solved: Unknown Unicast in ACI Fabric - Cisco Community

To support an application that is sensitive to latency and jitter, it is crucial to ensure that the Quality of Service (QoS) levels within the ACI fabric and the Inter-Pod Network (IPN) QoS policies are aligned. This alignment will help in maintaining consistent handling of the DSCP values set by the application (AF31 and CS6) as the packets traverse across the two ACI pods. By aligning the QoS levels and policies, the application’s packets are less likely to experience delays or drops, thus preserving the required performance levels for the application’s optimal functionality.

The control plane TEP (Tunnel Endpoint) IP address is a unique IP address assigned to each spine node within a Cisco ACI fabric. This IP address is used to establish MP-BGP EVPN (Multiprotocol Border Gateway Protocol Ethernet VPN) and VPNv4 (VPN version 4) adjacencies with the spine nodes in remote sites when configuring Cisco ACI Multi-Site. The control plane TEP IP enables the spine nodes to exchange routing information and network reachability for seamless integration of multiple sites into a single ACI fabric. References := Implementing Cisco Application Centric Infrastructure Official Cert Guide

To enable SSH communication between Web_EPG (Web Endpoint Group) and App_EPG (Application Endpoint Group), it’s necessary to apply a configuration that allows bidirectional communication while not restricting ports based on their directionality. By enabling “Apply Both Directions” and disabling “Reverse Filter Ports,” this ensures that the filter allows SSH packets to flow from Web_EPG to App_EPG and vice versa without any restrictions based on the port’s direction, which is essential for establishing an SSH session. References := ( Implementing Cisco Application Centric Infrastructure Official Cert Guide )

 In Cisco ACI fabric, when a Layer 2 unknown unicast packet is encountered, the fabric does not drop the packet. Instead, it uses a flooding mechanism to ensure that the packet reaches its potential destination. This is achieved by utilizing the VRF (Virtual Routing and Forwarding) Outer Multicast Group ID associated with the Bridge Domain (BD) to which the unknown destination MAC address belongs. By doing so, Cisco ACI ensures that all endpoints within the BD have an opportunity to receive and process the packet if they are indeed the intended recipient. References: Implementing Cisco Application Centric Infrastructure Official Cert Guide

In Cisco ACI, Virtual Routing and Forwarding (VRF) instances are used to create separate routing tables for network traffic management. An unenforced VRF does not apply policies or contracts for communication between endpoints, allowing free communication without the need for explicit permissions. By implementing an unenforced VRF in the common tenant and mapping all required Bridge Domains (BDs) to it, each department’s BDs can communicate with one another without configuring contracts or VRF route leaking, thus meeting the company’s requirement for redesigning their networking architecture. References: Implementing Cisco Application Centric Infrastructure Official Cert Guide

Before associating a schema with a newly configured site in Cisco ACI Multi-Site Orchestrator, it’s essential to configure a provider. This establishes a communication link between the orchestrator and the sites, enabling proper deployment and management of objects across multiple sites.

Removing pre-existing Fibre Channel over Ethernet (FCoE) configurations from Nexus devices is necessary to ensure compatibility with Cisco ACI mode. FCoE configurations are not supported in ACI mode, and their presence can hinder the migration process2.

The topology change notification (TCN) in Spanning Tree Protocol (STP) triggers a flush of the MAC address table. When a leaf node receives a TCN, it flushes the MAC address entries associated with the VLANs affected by the topology change. In this case, since the TCN is related to VLAN 101, the ACI fabric will flush all endpoints associated with VLAN 101 in bridge domain BD10123 on the leaf node.

The minimum MTU value that must be supported by the ISN to allow control plane endpoint information exchange between sites in a Cisco ACI Multi-Site setup with default settings is 1554 bytes (B). This accounts for the standard MTU of 1500 bytes plus additional overhead for VXLAN encapsulation. An MTU of 9000 (A) or 9100 © is not the minimum required, and 1600 (D) is not related to the default fabric settings5. References := (Multi-site / Multi-Pod MTU Jumbo Frames5)
