Fix all of the following violations that were found against the API server:-

 a. Ensure that the RotateKubeletServerCertificate argument is set to true.

apiVersion: v1

kind: Pod

metadata:

creationTimestamp: null

labels:

component: kubelet

tier: control-plane

name: kubelet

namespace: kube-system

spec:

containers:

- command:

- kube-controller-manager

+ - --feature-gates=RotateKubeletServerCertificate=true

image: gcr.io/google_containers/kubelet-amd64:v1.6.0

livenessProbe:

failureThreshold: 8

httpGet:

host: 127.0.0.1

path: /healthz

port: 6443

scheme: HTTPS

initialDelaySeconds: 15

timeoutSeconds: 15

name: kubelet

resources:

requests:

cpu: 250m

volumeMounts:

- mountPath: /etc/kubernetes/

name: k8s

readOnly: true

- mountPath: /etc/ssl/certs

name: certs

- mountPath: /etc/pki

name: pki

hostNetwork: true

volumes:

- hostPath:

path: /etc/kubernetes

name: k8s

- hostPath:

path: /etc/ssl/certs

name: certs

- hostPath:

path: /etc/pki

name: pki

  b. Ensure that the admission control plugin PodSecurityPolicy is set.

audit: "/bin/ps -ef | grep $apiserverbin | grep -v grep"

tests:

test_items:

- flag: "--enable-admission-plugins"

compare:

op: has

value: "PodSecurityPolicy"

set: true

remediation: |

Follow the documentation and create Pod Security Policy objects as per your environment.

Then, edit the API server pod specification file $apiserverconf

on the master node and set the --enable-admission-plugins parameter to a

value that includes PodSecurityPolicy :

--enable-admission-plugins=...,PodSecurityPolicy,...

Then restart the API Server.

scored: true

c. Ensure that the --kubelet-certificate-authority argument is set as appropriate.

audit: "/bin/ps -ef | grep $apiserverbin | grep -v grep"

tests:

test_items:

- flag: "--kubelet-certificate-authority"

set: true

remediation: |

Follow the Kubernetes documentation and setup the TLS connection between the

apiserver and kubelets. Then, edit the API server pod specification file

$apiserverconf on the master node and set the --kubelet-certificate-authority

parameter to the path to the cert file for the certificate authority.

--kubelet-certificate-authority=

scored: true

Fix all of the following violations that were found against the ETCD:-

a. Ensure that the --auto-tls argument is not set to true

Edit the etcd pod specification file $etcdconf on the master

node and either remove the --auto-tls parameter or set it to false.

--auto-tls=false

b. Ensure that the --peer-auto-tls argument is not set to true

Edit the etcd pod specification file $etcdconf on the master

node and either remove the --peer-auto-tls parameter or set it to false.

--peer-auto-tls=false

$ vim /etc/kubernetes/log-policy/audit-policy.yaml

- level: RequestResponse

userGroups: ["system:nodes"]

- level: Request

resources:

- group: "" # core API group

resources: ["persistentvolumes"]

namespaces: ["frontend"]

- level: Metadata

resources:

- group: ""

resources: ["configmaps", "secrets"]

- level: Metadata

$ vim /etc/kubernetes/manifests/kube-apiserver.yaml

Add these

- --audit-policy-file=/etc/kubernetes/log-policy/audit-policy.yaml

- --audit-log-path=/var/log/kubernetes/logs.txt

- --audit-log-maxage=5

- --audit-log-maxbackup=10

Explanation[desk@cli] $ ssh master1

[master1@cli] $ vim /etc/kubernetes/log-policy/audit-policy.yaml

apiVersion: audit.k8s.io/v1 # This is required.

kind: Policy

# Don't generate audit events for all requests in RequestReceived stage.

omitStages:

- "RequestReceived"

rules:

# Don't log watch requests by the "system:kube-proxy" on endpoints or services

- level: None

users: ["system:kube-proxy"]

verbs: ["watch"]

resources:

- group: "" # core API group

resources: ["endpoints", "services"]

# Don't log authenticated requests to certain non-resource URL paths.

- level: None

userGroups: ["system:authenticated"]

nonResourceURLs:

- "/api*" # Wildcard matching.

- "/version"

# Add your changes below

- level: RequestResponse

userGroups: ["system:nodes"] # Block for nodes

- level: Request

resources:

- group: "" # core API group

resources: ["persistentvolumes"] # Block for persistentvolumes

namespaces: ["frontend"] # Block for persistentvolumes of frontend ns

- level: Metadata

resources:

- group: "" # core API group

resources: ["configmaps", "secrets"] # Block for configmaps & secrets

- level: Metadata # Block for everything else

[master1@cli] $ vim /etc/kubernetes/manifests/kube-apiserver.yaml

apiVersion: v1

kind: Pod

metadata:

annotations:

kubeadm.kubernetes.io/kube-apiserver.advertise-address.endpoint: 10.0.0.5:6443

labels:

component: kube-apiserver

tier: control-plane

name: kube-apiserver

namespace: kube-system

spec:

containers:

- command:

- kube-apiserver

- --advertise-address=10.0.0.5

- --allow-privileged=true

- --authorization-mode=Node,RBAC

- --audit-policy-file=/etc/kubernetes/log-policy/audit-policy.yaml #Add this

- --audit-log-path=/var/log/kubernetes/logs.txt #Add this

- --audit-log-maxage=5 #Add this

- --audit-log-maxbackup=10 #Add this

output truncated

Note: log volume & policy volume is already mounted in vim /etc/kubernetes/manifests/kube-apiserver.yaml so no need to mount it.
